| 50Hz-3000rpm（转/分钟） | 60Hz-3600rpm（转/分钟） | ||||||||
| Φ直径 | 叠压高度（L1mm） lamination thickness |
输出功率kVA output power cos Φ=1 |
驱动功率 driving power |
输出功率kVA output power cos Φ=1 |
驱动功率 driving power |
||||
| s1 | s1 | kw | Ⅱ% | s1 | s2 | kw | Ⅱ% | ||
| Φ190 | 85 | 2.8 | 3.1 | 3.50 | 72 | 3.4 | 3.7 | 4.3 | 79 |
| 100 | 3.3 | 3.6 | 4.07 | 74 | 4.0 | 4.4 | 5.0 | 80 | |
| 125 | 4 | 4.4 | 4.88 | 74 | 4.8 | 5.3 | 5.9 | 81 | |
| 140 | 5 | 5.5 | 6.02 | 78 | 6.0 | 6.6 | 7.3 | 82 | |
| 155 | 6.0 | 6.6 | 7.2 | 78 | 7.0 | 7.7 | 7.74 | 84 | |
