| 50Hz-3000rpm（转/分钟） | 60Hz-3600rpm（转/分钟） | ||||||||
| Φ直径 | 叠压高度（L1mm） lamination thickness |
输出功率kVA output power cos Φ=1 |
驱动功率 driving power |
输出功率kVA output power cos Φ=1 |
驱动功率 driving power |
||||
| s1 | s1 | kw | Ⅱ% | s1 | s2 | kw | Ⅱ% | ||
| Φ160 | 50 | 1 | 1.1 | 1.4 | 70 | 1.2 | 1.3 | 1.7 | 71 |
| 60 | 1.3 | 1.4 | 1.8 | 70 | 1.6 | 1.7 | 2.2 | 72 | |
| 70 | 1.5 | 1.7 | 2.1 | 70 | 1.8 | 2.0 | 2.5 | 73 | |
| 85 | 2 | 2.2 | 2.7 | 72 | 2.4 | 2.6 | 3.2 | 75 | |
| 110 | 2.5 | 2.8 | 3.2 | 72 | 3.0 | 3.3 | 3.8 | 78 | |
| 120 | 2.8 | 3.1 | 3.5 | 72 | 3.4 | 3.7 | 4.2 | 80 | |
